Offering lens options each featuring 100mm eye relief and an expansive field of view, the TS34 and TS36 series assures a comfortable viewing experience. The rubber eyepiece ensures discreet observation at night, maintaining the user's familiarity with traditional daytime optic usage.
Thermal imaging is brought to life on the ultra-clear IPS display, boasting an 800*800 resolution. The innovative picture-in-picture (PIP) function provides a sharp heat signature, significantly enhancing eye observation comfort.
The scope's circular display design facilitates a holistic view of the image. Combined with a wide field of view (FOV), it helps you to intuitively understand the target's position relative to the environment.
The TS34 and TS36 series are equipped with a 384×288 pixel or 640*480 pixel 12μm vanadium oxide (VOx) sensor. With an NETD of ≤25mK and 12µm pixel pitch, users can enjoy striking contrast and high resolution when locating targets.
Choose from 19/25/35/45mm optical objective lenses to cater to your hunting environment. The wider the field of view, the broader your perspective; the narrower the field of view, the greater your viewing distance.
The TS3x series employs our proprietary software and a superior image enhancement algorithm for heightened infrared spectrum sensitivity, enhancing image visibility. The IREA ensures an enriched image with reduced distortion and greater detail, even for distant targets.
The device automatically records the shooting process in 20-second intervals upon detecting recoil, allowing you to effortlessly capture that perfect hunting moment.
The multi-function control knob enables quick and easy switching between functions within seconds.
Built-in WiFi allows connection to your phone, PC, or tablet for use as an external viewfinder, enabling instant image and video transfer on the go.
With our intuitive and convenient firmware update process, you can easily keep your device up to date with the latest firmware using a TF card at home.
Powered by a 18650 Li-ion battery, the device offers up to 5 hours of operation depending on usage, ensuring you'll never run out of power during a hunting trip.
Equipped with an HDMI output and USB Type-C power supply for versatile connectivity.
With an IP67 waterproof rating, the TS32 and TS36 series deliver dependable performance in a variety of harsh outdoor environments, including wet and moist weather conditions and snow.
The manual focus lever provides a smooth, precise, and gentle focus, enhancing target acquisition with its excellent design.
Choose from 6 different reticle styles and 4 different reticle colors. After centering the crosshair, the device returns to zero, with options for centering left and right.
MODEL |
TS34-25 (LRF) |
TS34-35 (LRF) |
TS34-45 (LRF) |
TS36-25 (LRF) |
TS36-35 (LRF) |
TS36-45 (LRF) |
Thermal Sensor
|
384 x 288
|
384 x 288
|
384 x 288
|
640 x 512
|
640 x 512
|
640 x 512
|
Objective lens
|
25mm |
35mm
|
45mm
|
25mm
|
35mm
|
45mm
|
Magnification, x
|
2.6x (4x zoom) | 3.7x (6x zoom) | 4.7x (8x zoom) | 1.6x (4x zoom) | 2.8x (4x zoom) | 3.5x (4x zoom) |
Field of view (Horizontal), degrees
|
7.9° | 5.6° | 4.4° | 13.1° | 9.4° | 7.3° |
Detection range (person), m
|
1100
|
1400 |
1700
|
1200
|
1500
|
1800
|
Sensor (Thermal)
|
||||||
Type
|
uncooled VOx
|
uncooled VOx
|
uncooled VOx
|
uncooled VOx
|
uncooled VOx
|
uncooled VOx
|
Resolution, pixels
|
384 x 288
|
384 x 288
|
384 x 288
|
640 x 512
|
640 x 512
|
640 x 512
|
Pixel Pitch
|
12 um
|
12 um
|
12 um
|
12 um
|
12 um
|
12 um
|
NETD
|
<25 mK
|
<25 mK
|
<25 mK
|
<25 mK
|
<25 mK
|
<25 mK
|
Frame rate, Hz
|
50
|
50 |
50
|
50 |
50
|
50 |
Optics
|
|
|
|
|
|
|
Objective lens
|
25mm |
35mm
|
45mm
|
25mm
|
35mm
|
45mm
|
Magnification, x
|
2.6x (4x zoom) | 3.7x (6x zoom) | 4.7x (8x zoom) | 1.6x (4x zoom) | 2.2x (6x zoom) | 2.8x (8x zoom) |
Field of view (Horizontal), degrees
|
7.9° | 5.6° | 4.4° | 13.1° | 9.4° | 7.3° |
Display
|
|
|
|
|
|
|
Resolution, pixels
|
800x800 IPS LCD |
800x800 IPS LCD
|
800x800 IPS LCD
|
800x800 IPS LCD
|
800x800 IPS LCD
|
800x800 IPS LCD
|
Thermal Palettes
|
White Hot, Black Hot, Red Hot, Edge, Iron Red, Sky |
White Hot, Black Hot, Red Hot, Edge, Iron Red, Sky
|
White Hot, Black Hot, Red Hot, Edge, Iron Red, Sky |
White Hot, Black Hot, Red Hot, Edge, Iron Red, Sky
|
White Hot, Black Hot, Red Hot, Edge, Iron Red, Sky |
White Hot, Black Hot, Red Hot, Edge, Iron Red, Sky
|
Range Performance
|
|
|
|
|
|
|
Detection range (person), m
|
1100
|
1400 |
1700 |
1200
|
1500
|
1800
|
Detection range (vehicle), m
|
2200
|
2600
|
3000
|
2500
|
2900
|
3300
|
Laser Rangefinder
|
(optional LRF)
|
(optional LRF)
|
(optional LRF)
|
(optional LRF)
|
(optional LRF)
|
(optional LRF)
|
Safety class for laser equipment according to IEC 60825-1:2014
|
-
|
-
|
-
|
-
|
-
|
-
|
Wavelength, nm
|
-
|
-
|
-
|
-
|
-
|
-
|
Max. measuring range, m
|
1000
|
1000
|
1000
|
1000
|
1000
|
1000
|
Measurement accuracy, m
|
±1
|
±1
|
±1
|
±1
|
±1
|
±1
|
Min. Measuring Range, m
|
-
|
-
|
-
|
-
|
-
|
-
|
Laser Pointer (red optical)
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Reticle
|
|
|
|
|
|
|
Picture in Picture
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Number of preloaded reticles
|
6 (4 colours)
|
6 (4 colours)
|
6 (4 colours)
|
6 (4 colours)
|
6 (4 colours)
|
6 (4 colours)
|
Number of Zero Profiles available
|
tba
|
tba
|
tba
|
tba
|
tba
|
tba
|
WiFi Connection
|
Yes (Roadcam App)
|
Yes (Roadcam App)
|
Yes (Roadcam App)
|
Yes (Roadcam App)
|
Yes (Roadcam App)
|
Yes (Roadcam App)
|
Video Recorder
|
Micro SD Card
(Max. 128Gb storage)
|
Micro SD Card
(Max. 128Gb storage)
|
Micro SD Card
(Max. 128Gb storage)
|
Micro SD Card
(Max. 128Gb storage)
|
Micro SD Card
(Max. 128Gb storage)
|
Micro SD Card
(Max. 128Gb storage)
|
HDMI Output
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Microphone
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Recoil-Activated Video Recording
|
Yes</
|
