Main |
|
Max. Resolution |
3840 × 2160 |
Frame Rate |
50 Hz (4K), 100 Hz (1080P) |
Lens (Focal Length) |
40 mm, F2.0 |
Detection Range |
Day: 800 m |
Min. Focusing Distance |
2 m |
Magnification |
3.5× to 20.5× (5.8×) |
Field of View |
10.7° × 6.1° / 18.7 m × 10.1 m @100 m |
Image Display |
|
Display |
1920 × 1080, 0.49 inch, OLED |
Image Mode |
Day, Night, Auto, Green, Yellow |
Exit Pupil |
6 mm |
Eye Relief |
45 mm |
Diopter (Range) |
-5 D to 5 D |
System |
|
Record Video |
On-board Video Recording |
Record Video Resolution |
1920 × 1080 |
Capture Snapshot |
Yes |
Audio Recording |
Yes |
Recoil-activation Recording |
Yes |
Standby Mode |
Yes |
Storage |
Built-in EMMC (32 GB) |
PIP |
Yes |
Freeze Zeroing |
Yes |
Zeroing Profiles |
5 |
Max. Recoil |
1000 g/0.4 ms |
Hotspot |
Yes |
Ballistic Calculation |
Yes |
Click Value |
1 click = 1cm @ 100 m |
Power Supply |
|
Battery Type |
One Rechargeable Lithium Battery (Internal), One Replaceable and Rechargeable18650 Battery (External) |
Battery Operating Time |
7 hours of Continuous Running (@25°C, Hotspot off) |
Power Supply |
5 VDC/2 A, USB Type-C Interface |
General |
|
Mounting |
Standard 30 mm |
Protection Level |
IP67 |
Working Temperature |
-30°C to 55°C (-22°F to 131°F) |
Dimension |
280.7 mm × 86.1 mm × 66.3 mm (without eyepiece) |
Weight |
474 g without External Battery |
Laser Rangefinder |
|
Safety Class for Laser |
Class1 |
Wavelength |
905 nm |
Min. Measuring Range |
3 m |
Max. Measuring Range |
1000 m |
Measurement Accuracy |
±1 m |
